Massive GPU Package: The leaked PCB design for the GeForce RTX 5090 showcases a large BGA package for the GB202 GPU, indicating a significant performance leap with enhanced processing power and efficiency.
GDDR7 Memory: The PCB features 16 solder pads around the GPU core, suggesting configurations of up to 32GB, 48GB, or even 64GB of next-gen GDDR7 memory, offering higher data transfer speeds and better energy efficiency.
Single 12V-2x6 Power Connector: The inclusion of a single 12V-2x6 power connector capable of delivering up to 600W of power highlights the card's potential for high performance while addressing previous issues with power connectors.
PCIe 5.0 Support: The RTX 5090 is set to support PCIe 5.0, doubling the external bandwidth to 64GT/s, which enhances data transfer rates and overall system performance.
DisplayPort 2.1a: Upgrading to DisplayPort 2.1a, the RTX 5090 supports higher bandwidth, enabling impressive display capabilities such as 8K resolution at 240 Hz or 16K at 60 Hz with DSC.
Enhanced Capacitor Layout: The PCB design includes more than 40 capacitors, which improves power delivery and stability, ensuring reliable performance under heavy loads.
Third-Party Customization: The absence of NVIDIA branding on the leaked PCB suggests it might belong to a third-party vendor, indicating potential for customized versions with additional features and enhancements.
